Wireless Sniffer Board 55
14
Wireless Sniffer Board
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as the
back panel) on the computer.
NOTICE: Handle components and cards by their edges, and avoid touching pins
and contacts.
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove any installed ExpressCards from the ExpressCard slot.
3 Remove the palm rest (see "Palm Rest" on page 49).
4 Disconnect the wireless sniffer board cable from the system board.
5 Remove the screw from the sniffer board and remove it from the computer
base.
1 screw
1
