Installing System Components
91
Figure 3-26. Removing and Installing the System Battery
Installing the System Battery
1 Push the new battery into the battery socket as shown in Figure 3-26.
NOTE:
The side of the battery labeled "+" (plus sign) must face toward the
open side of the battery socket.
2 Close the system. See "Closing the System" on page 47.
3 Reconnect the system to the electrical outlet and turn on the system and
attached peripherals.
4 Enter the System Setup program to confirm that the battery operates
properly. See "Using the System Setup Program" on page 29.
5 From the main screen, select System Time to enter the correct time and
date.
6 Re-enter any system configuration information that is no longer displayed
on the System Setup screens, and then exit the System Setup program.
7 To test the newly installed battery, see "Troubleshooting the System
Battery" on page 114.
8 After an hour, reconnect the system to a power source and turn it on.
1 battery socket 2 system battery
3 tab
2
3
1
