Removing and Installing Parts: Dell XPS 710 H2C Edition Service Manual
file:///C|/Preeji_working%20folder/Projects/E-Doc/Dimension%20and%20XPS/xps-710-h2c/SM/parts.htm[3/13/2013 11:45:23 AM]
1
hard drive
2
hard drive bay
NOTICE:
Ensure that all connectors are properly cabled and firmly seated.
7. Connect the power cable to the hard drive.
8. Connect the hard drive data cable to the hard drive.
