Understanding the Tool Box Menus

117

Adjust Fusing Unit

Purpose:
To specify the optimum temperature settings for printing for the fusing unit. To decrease the temperature, set

negative values. To increase, set positive values.
The default settings may not give the best output on all paper types. When the printed paper has curled, try to

decrease the temperature. When the toner does not fuse on the paper properly, try to increase the temperature.

NOTE:

The print quality changes depending on the values you select for this item.

Values:

Color Registration Adjustment

Purpose:
To set Color Registration Adjustment (individual yellow, magenta, cyan correction) settings. When Auto

Registration Adjustment is set to On, the printer prints the color registration chart and adjusts the color registration

by using the chart. Color registration adjustments need to be made during the initial setup of the printer or when

the printer is moved to a different location.
Values:

Plain

Available Range:

-3 – +3

Plain Thick

Available Range:

-3 – +3

Recycled

Available Range:

-3 – +3

Covers

Available Range:

-3 – +3

Coated

Available Range:

-3 – +3

Envelope

Available Range:

-3 – +3

Label

Available Range:

-3 – +3

Apply New Settings

After you complete the settings, click Apply New Settings to apply the changes.

Restart printer to apply new settings

Click Restart printer to apply new settings to apply the changes.

Auto Registration

Adjustment

On

Automatically adjusts color registration.

Off

Does not automatically adjust color registration.

Auto Correct

*1

Click Start to automatically correct color registration.

Print Color Regi Chart

*1, *2

Click Start to open the Print Color Regi Chart window, and then select the

paper size and click OK to print a color registration chart.
