Dell™ Printer Configuration Web Tool
103
TCP/IP
Purpose:
To configure the IP address, subnet mask, and gateway address of the printer.
Values:
TCP/IP Settings
IP Mode
Specifies the IP mode.
Host Name
Specifies the host name.
IPv4
IP Address Mode
Selects the IP address mode.
Manual IP Address
Manually sets the IP address.
Manual Subnet Mask
Manually sets the subnet mask.
Manual Gateway Address
Manually sets the gateway address.
IPv6
Enable Stateless Address
To enable the stateless address.
Use Manual Address
To set the IP address manually.
Manual Address
Manually sets the IP address. To
specify an IPv6 address, enter the
address. Followed by a slash (/) and
then "64". For details, consult your
system administrator.
Manual Gateway Address
Manually sets the gateway address.
DNS
DNS Domain Name
Specifies the domain name of the domain name server. Up to 255
alphanumeric characters, periods, and hyphens can be used. If you
need to specify more than one domain name, separate them using a
comma or semicolon.
IPv4
Get DNS Server Address
from DHCP
Specifies if the printer receives the
DNS server address automatically
from the DHCP server.
Manual DNS Server Address Sets the DNS server address.
IPv6
Get DNS Server Address
from DHCPv6-lite
Specifies if the printer receives the
DNS server address automatically
from the DHCPv6-lite server.
Manual DNS Server Address Sets the DNS server address.
Priority to IPv6 DNS Name
Resolution
Specifies whether to enable the DNS
Name Resolution feature.
LPD
Connection Time-Out
Sets the connection time-out period from 1 to 1000 seconds.
IP Filter (IPv4)
Click IP Filter (IPv4) to set the IP filter settings on the IP Filter
(IPv4) page.
Port9100
Port Number
Sets the port number from 9000 to 9999.
Connection Time-Out
Sets the connection time-out period between 1 and 1000 seconds.
IP Filter (IPv4)
Click IP Filter (IPv4) to set the IP filter settings on the IP Filter
(IPv4) page.
