118

Understanding the Tool Box Menus

Adjust Altitude

Purpose:
To specify the altitude of the location where the printer is installed.
The discharge phenomenon for charging the photo conductor varies with barometric pressure. Adjustments are

performed by specifying the altitude of the location where the printer is being used.

NOTE:

An incorrect altitude adjustment setting leads to poor printing quality, incorrect indication of remaining toner.

Values:

Registration

Adjustments

*1

Y(Yellow)

Available Range:

-5–+5

Specifies lateral (perpendicular to paper feed direction)

color adjustment values individually.

M(Magenta)

Available Range:

-5–+5

C(Cyan)

Available Range:

-5–+5

LY(Left Yellow)

Available Range:

-5–+5

Specifies process (paper feed direction) color

adjustment values individually.

LM(Left Magenta)

Available Range:

-5–+5

LC(Left Cyan)

Available Range:

-5–+5

RY(Right Yellow)

Available Range:

-5–+5

RM(Right Magenta)

Available Range:

-5–+5

RC(Right Cyan)

Available Range:

-5–+5

Apply New Settings

After you complete the settings, click Apply New Settings to apply the

changes.

Restart printer to apply new settings

Click Restart printer to apply new settings to apply the changes.

*1 This item is available only when Auto Registration Adjustment is set to Off.
*2 The color registration chart prints a lattice pattern of yellow, magenta, and cyan lines. On the chart, find the values on the right side that

are next to the line that is perfectly straight for each of the three colors. If the value for this line is 0, color registration is not needed. If
the value for this line is any value other than 0, specify the adjustment values under Registration Adjustments.

0 meter

Specifies the altitude of the location where the printer is installed.

1000 meters
2000 meters
3000 meters
Apply New Settings

After you complete the settings, click Apply New Settings to apply the changes.

Restart printer to apply new settings

Click Restart printer to apply new settings to apply the changes.
