About Your Computer 21
N E T WO R K C O N N EC T O R (RJ-45)
NOTICE: The network connector is slightly larger than the modem connector. To avoid damaging the computer, do
not plug a telephone line into the network connector.
S- V I D E O TV- O U T CO N N E C T O R
USB C O N N E C T O RS
1 network connector (RJ-45) 2 S-video TV-out connector 3 USB connectors (2)
4 modem connector (RJ-11) 5 serial connector 6 VGA connector
7 AC adapter connector 8 air vents
Connects the computer to a network. The two lights next to
the connector indicate the status of both the connection
and the transfer of information for wired network
communications.
For information on using the network adapter, see the device
user’s guide supplied with your computer. See "Finding
Information" on page 11.
Connects your computer to a TV. For more information, see
"Connecting Your Computer to a TV or Audio Device" on
page 54.
Connect USB devices, such as a mouse, keyboard, or printer.
You can also connect the optional floppy drive directly to a
USB connector using the optional floppy drive cable.
8 1 2 3 4 5 6 7
