Before You Begin

Keyboard

CAUTION:

Before you begin any of the procedures in this section, follow the safety instructions in the

Product

Information Guide.

NOTICE:

To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically

touching an unpainted metal surface (such as a connector on the back of the computer).

1 Follow the procedures in "Before You Begin" on page 111.
2 Remove the hinge cover (see "Hinge Cover" on page 115).
3 Remove the three screws at the top of the keyboard.

NOTICE:

The keycaps on the keyboard are fragile, easily dislodged, and time-consuming to replace. Be careful

when removing and handling the keyboard.

4 Lift the keyboard only enough to hold it up and slightly forward to allow access to the keyboard

connector on the system board.

5 To release the keyboard cable from the connector on the system board, rotate the plastic bar on the

keyboard connector.
