Before You Begin 125
NOTICE: To avoid scratching the palm rest when replacing the keyboard, hook the tabs along the front edge of the
keyboard into the palm rest, and then secure the keyboard in place.
6 To replace the keyboard, connect the keyboard cable to the connector on the system board.
7 Place the tabs along the front edge of the keyboard into the palm rest, and lay the keyboard down on
the palm rest.
8 Replace the three screws at the top of the keyboard.
9 Replace the hinge cover.
Internal Card With Bluetooth
®
Wireless Technology
CAUTION: Before performing the following procedures, read the safety instructions in your Product Information
Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching a connector on the back panel of the computer.
NOTICE: To prevent damage to the system board, remove the main battery before you service the computer.
If you ordered an internal card with Bluetooth wireless technology with your computer, it is already
installed.
1 Follow the procedures in "Before You Begin" on page 111.
2 Remove the hinge cover (see "Hinge Cover" on page 115)
3 Pull the card cable connector out from the metal tab.
1 keyboard 2 keyboard screws 3 cable connector
4 keyboard connector
3
2
1
