CANON Digital Galvano Scanner System GM-1000 Series
Users Manual 1.20
52
(Scope and Measurement window explanation)
①
Step response
waveform
Displays the step response waveform by the deviation from the
target position.
0 usec (left edge) position is the movement start time.
②
Cursor location
(Step response
waveform)
①
Displays the cursor location in the step response waveform
graph.
③
Scope and Measurement window
①
②
④
⑤
⑥
⑦
