CANON Digital Galvano Scanner System GM-1000 Series
Users Manual 1.20
108
9. Parameters
9.1. List of Parameters
ID Parameter Name
0 CW Limit
1 CCW Limit
2 Max Velocity
3 In-position Range
4 Settling Check Time
5 In-position Overtime
6 LQ Control Gain
7 Torque Constant
8 Total Inertia
9 Motor Current Limit
10 Encoder Wave per Rotation
11 Origin Clear Timing (Head 1)
12 Servo Sampling Time
13 High Speed Serial Data to angle gain
14 Origin Clear Timing (Head 2)
15 High Speed Serial Data Offset
16 #1 Digital Notch Filter Frequency
17 #1 Digital Notch Filter Q
18 #1 Digital Notch Filter Depth
19 #2 Digital Notch Filter Frequency
20 #2 Digital Notch Filter Q
21 #2 Digital Notch Filter Depth
22 Low-pass Filter Cutoff Frequency
23 #1 Analog Notch Filter Frequency
24 #2 Analog Notch Filter Frequency
25 #3 Analog Notch Filter Frequency
26 Cycle Time of Raster Scan
27 Duty of Raster Scan
28 Scan Angle of Raster Scan
30 Interval Time of Raster Scan
31 Start Position of Raster Scan
32 Torque Peak Offset
33 Acceleration Time
34 Deceleration Time
40 Feed-forward Gain
42 Overshoot Control
44 PES Limit
45 Loop Gain Fine Adjustment
