CANON Digital Galvano Scanner System GM-1000 Series
Users Manual 1.20
33
2.8.3.2. High-speed serial communication motor drive timing
The following diagram indicates actual motor drive signal output timing when the high-speed serial
communication position command is received.
COMMAND
XY-2 COMMAND
FRAME SYNC
DSP Sampling Clock
Output to MOTOR
10us
10us
CONTROL
5us
5us
20us
Target
Position1 Target
Position2 Target
Position3
Target
Position1
5us
COMMAND
XY-2 COMMAND
FRAME SYNC
DSP Sampling Clock
Output to MOTOR
10us
10us
CONTROL
5us
5us
20us
Target
Position1 Target
Position2 Target
Position3
Target
Position1
5us
