Optional cables – Canon GM-1000 User Manual
Page 17
CANON Digital Galvano Scanner System GM-1000 Series
Users Manual 1.20
17
2.7. Optional Cables
Optional cables are prepared for power and communications cables.
Connector pin assignment for each cable as follows.
Verify details with your sales representative.
Option cables
①
Power cable (+5 V)
②
Power cable (+24 V)
③
RS-232C
cable
④
High-speed serial communication cable
①
Power Cable +5 V
②
Power Cable +24 V
