CANON Digital Galvano Scanner System GM-1000 Series
Users Manual 1.20
122
Parameter ID 45
Parameter
Name
Loop Gain Fine Adjustment
Data Loop Gain Fine Adjustment (Unit: Multiple × 1000)
Return Value 0: Parameter setting successful
1: Parameter setting unsuccessful
Explanation This parameter makes fine adjustments to the servo's loop gain (inertia of the motor
and mirror, and the torque constant of the motor are related).
Note: This is usually set appropriately at shipping.
Related
Command
/Parameter
Parameter ID 48
Parameter
Name
VR head1 AB offset
Data A/B-phase offset of encoder VR adjustment head 1 (Unit: none)
Return Value 0: Parameter setting successful
1: Parameter setting unsuccessful
Explanation This parameter is used to adjust the offset of encoder signal.
Note: This is usually set appropriately at shipping.
Related
Command
/Parameter
Parameter ID 49
Parameter
Name
VR head1 A gain
Data A-phase amplitude of encoder VR adjustment head 1 (Unit: none)
Return Value 0: Parameter setting successful
1: Parameter setting unsuccessful
Explanation This parameter is used to adjust the A-phase amplitude of the encoder signal.
Note: This is usually set appropriately at shipping.
Related
Command
/Parameter
Parameter ID 50
Parameter
Name
VR head1 B gain
Data B-phase amplitude of encoder VR adjustment head 1 (Unit: none)
Return Value 0: Parameter setting successful
1: Parameter setting unsuccessful
Explanation This parameter is used to adjust the B-phase amplitude of the encoder signal.
Note: This is usually set appropriately at shipping.
Related
Command
/Parameter
