Using LANVIEW
DLE22-MA, DLE32-MA, DLE23-MA and DLE33-MA User’s Guide 4-3
Table 4-1 LANVIEW LEDs
LED Color State Recommended Action
CPU
Off Power off. Power up chassis.
Red
Blinking. Hardware
failure has occurred. Contact your DIGITAL
representative.
Solid. Resetting,
normal power up reset.
No action. If LED remains Red
for several minutes, contact
your DIGITAL representative.
Amber Blinking. Crippled.
Contact your DIGITAL
representative.
Solid. Testing.
No action. If LED remains
Amber for several minutes,
contact your DIGITAL
representative.
Green Solid. Functional. No action.
Amber
and
Green Booting. Blinks amber
and green while
booting.
No action.
RX
Off
No link. No activity.
Port enabled or
disabled.
No error.
Green
Solid. Port enabled,
link, no activity. No error.
Blinking. Port
disabled, link. No error.
Amber
Flashing. Port
enabled, link, activity.
No error.
Red Diagnostic failure.
Contact your DIGITAL
representative for assistance.
