Chapter 5: Local Management
5-86 DLE22-MA,DLE32-MA,DLE23-MA and DLE33-MA User’s Guide
5.26 BROADCAST SUPPRESSION SCREEN
The Broadcast Suppression screen, Figure 5-31, allows the user to set a
desired limit of receive broadcast frames per port per second.
Access the Broadcast Suppression screen from the Module Specific
Configuration screen by using the arrow keys to highlight the
BROADCAST SUPPRESSION menu item and pressing ENTER. The
Broadcast Suppression screen displays.
Figure 5-31 Broadcast Suppression Screen
The Broadcast Suppression screen may not be available if the
operational mode of the module has been set to 802.1Q
SWITCHING. Refer to your Release Notes to see what
operational modes support Broadcast Suppression. Refer to
Section 5.15.9, Setting the Operational Mode, for instructions
on configuring the operational mode of the module.
Any broadcast frames received above the desired threshold
will be dropped.
