Switch Configuration Screen
DLE22-MA,DLE32-MA,DLE23-MA and DLE33-MA User’s Guide 5-57
Figure 5-23 Switch Configuration Screen
The following describe each field of the Switch Configuration screen:
Switch Address (Read-Only)
Displays the base MAC address of the switch.
Number of Ports (Read-Only)
Displays the total number of switched ports on the module.
Type of STA (Toggle)
Allows the user to set the method that switches use to decide which
switch is the controlling (Root) switch when two or more switches exist in
parallel (Spanning Tree Algorithm). Valid entries include IEEE, DEC,
and NONE. To set the STA, refer to Section 5.18.1.
Age Time (Modifiable)
Allows the user to set the amount of time (in seconds) the DLE2X-MA
and DLE3X-MA will keep an address in its switch table before discarding
it. The modules will discard an address from their switch table if they do
not receive a valid packet from the applicable address in the amount of
