User manual Scatec-10 / -15 29 / 44 Baumer Electric AG
Version 2011-03 www.baumer.com Frauenfeld, Switzerland
C10:
Pulse Delay
xxx ms
Output pulse delay in ms
value of output pulse delay in milliseconds
C11:
Pulse Delay
xxx mm
Output pulse delay in mm
value of output pulse delay in millimeters
C12:
Out@PlsTrain
0 = first
1 = last
Output pulse triggered by last edge
output pulse triggered by first edge of edge train
output pulse triggered by last edge of edge train
C13:
Tail.Suppr.
0 = stand
1 = extnd
Tail edge suppression
edge suppressed if it is followed by a retro-
reflective foil within the dead time
edge suppressed if it is followed by a retro-
reflective foil within the output pulse delay
time
C14:
ShrtP.Suppr.
0 = off
1 = on
Short pulse suppression
short edges will not be suppressed
short edges will be suppressed
C15:
Sensvty Mode
0 = stand
1 = custm
Sensitivity mode
standard sensitivity levels as defined in C16 will be
activated
sensitivity as defined by customer in C17 and in C18
will be activated
C16:
Sensvt Level
01 = high
02 = mid
03 = low
04 = v.low
Sensitivity level
highest
medium
low
very low
C17:
Threshold
xxx
Threshold
C18:
Hysteresis
xxx
Hysteresis
value of the hysteresis
