Crestron CEN-CN Ethernet/Cresnet Interface
Operations Guide - DOC. 5721 Ethernet/Cresnet Interface: CEN-CN
••
19
2. Enter the IP address of the configured CEN-CN and click the Connect
button. (Within the address, X and Y may range from 0 to 255. In the
example shown below, X is 1 and Y is 2.)
Connect TCP/IP Address
3. The message shown below signifies a successful connection.
Crestron Terminal Protocol Console Opened
4. Perform any of the diagnostics and features that the viewport provides.
Troubleshooting Communications via Ethernet
NOTE: Before performing this procedure, refer to “Hookup Diagram for Normal
Operation” on page 17 for cabling instructions.
You can PING the CEN-CN from a MS-DOS® prompt (Windows 95/98™) or a
Command Prompt (Windows NT™). When the CEN-CN is at address 192.168.1.2
(Within the address, X and Y may range from 0 to 255. In the example shown below,
X is 1 and Y is 2.), the unit should reply and there should be no packet loss, as
shown.
NOTE: Verify that the IP Settings of the CEN-CN are correct, and that the PC can
ping other devices that are on the CEN-CN's subnet.
MS-DOS or Command Screen
