Bio-Rad Mini-PROTEAN® Tetra Cell - Manual (Page 8)

4
1.3 Specifications
Casting Stand* Polycarbonate
Pin, retaining ring, and spring Stainless steel
Casting Frames* Polysulfone
Gray gaskets Thermoplastic rubber (gray)
Electrode Assembly Glass-filled polybutylene
terephthalate
Electrodes Platinum wire, 0.010 inches diameter
Gasket, electrode inner core Silicone rubber (green)
Mini Tank and Lid Polycarbonate
Sample Loading Guides** Delrin
Combs* Polycarbonate
Overall Size (W x L x H, cm) 12 x 16 x 18
Precast Gel Compatibility Ready Gel and Mini-PROTEAN
precast gels (for more information,
go to www.bio-rad.com/mpgels)
Voltage Limit 600 V DC and 500 W
Shipping Weight 2.0 kg
Maximum Sample Volume per Well
# Wells Well Width 0.75 mm 1.0 mm 1.5 mm
5 12.7 mm 20 µl 105 µl 160 µl
9 5.08 mm 33 µl 44 µl 66 µl
10 5.08 mm 33 µl 44 µl 66 µl
15 3.35 mm 20 µl 26 µl 40 µl
IPG 6.2 mm – 420 µl 730 µl
Prep/2-D
Reference well 3.1 mm 13 µl 17 µl 30 µl
Sample well 71.1 mm 310 µl 400 µl 680 µl
* US patent No. 6,162,342
** US patent No. 5,656,145
