RemoteVision User Manual
Operation
HB-0913-02
20
INSTRUMENT CONTROL
The Instrument Control function allows you to control 20/20 or 40/40 displays and
also allows you to set the lighting level on the instrument system.
20/20 and 40/40 Setup
The 20/20 and 40/40 setup page shows the currently
displayed functions on each 20/20 (or 40/40) display
To alter a displayed function
1. scroll up or down using the NavStick to select
the 20/20 display you wish to change
2. click the NavStick in – the selected 20/20 will
start flashing
3. scroll up/down to select one of the preset
functions stored in the 20/20 display
4. click the NavStick in to confirm your selection
If you wish to change one of the functions stored in
the 20/20 follow the above steps (1) and (2) to select
the function you wish to overwrite, then click the
NavStick to the right to enter the menu structure and
select a new function as you would for the
Instruments pages.
Back Lighting
The Instrument Control Back Lighting function adjusts
the lighting level intensity for system displays.
Note
Any displays set into Local lighting mode will not be
affected by the lighting control command from the
RemoteVision. Refer to the instrument user manual
for more information.
