Text
Use this tool to add text entries onto the network diagram.
Noise
Use this tool to place a manual noise point on the network. For example, use
it to mark the location of a known source of noise in an area by placing the
noise source onto the pipe location and adding a comment defining the source.
Pipe Join
Use this tool to create a pipe join.
Properties
Select this checkbox to open the properties display on the right side of the
window.
Zoom In
Use this option to zoom in on the display.
Zoom Out
Use this option to zoom out from the map.
Delete
Use this option to delete an item selected on the display. The Delete key on a
keyboard also may be used to delete a selected item. The software solicits a
confirmation before permanently deleting an item.
Snap to Grid
Use this tool to display/remove a grid and snap items on the display to the grid
intersections (when applicable).
