ADS Enigma/Enigma-Compact/Enigma-hyQ User Manual
65
Info Displays
Information displays
Logger Number
This represents the number of the logger, which also displays on the top of the
logger.
Critical Noise Value
This represents the critical nose value. The key to the values and colors is
available at the top of the window.
Sound Graph
This is a graphical representation of the sound recorded by the logger.
Network Button
Clicking on the Network button displays the Network screen. This screen
allows the user to develop a graphical representation of the pipe network
showing pipe lengths and logger locations. It includes two tabs:
Network
Maps
The Network screen can be used to copy pipe data into the database and as an
alternate method for entering pipe data (instead of through the Analysis
screen). Entering pipe data in the Analysis screen does not create the pipe
network on the Network screen.
Both the Network Screen and Manual entry modes are available; however,
both cannot be used simultaneously. Select the mode from the Tools > Pipe
Data Entry menu. A check () displays beside the currently selected mode.
Switch between modes as required. When the manual (via Analysis) mode is
active, the network background displays in blue.
The network screen option enables the user to draw the network as required
and enter pipe data for the individual sections. This adds the pipe information
to the database and creates an illustration of the pipe network. When drawing
