Assemble opener mounts to wing – Great Plains NTA3007HD Predelivery Manual User Manual
Page 46
42 NTA907HD
166-207Q
03/29/2010
Assemble Opener Mounts to Wing
(see Parts Manual section: Opener Mount to Wing)
(see Operator Manual section: Opener Sub-Frame
Adjustment)
Refer to Figure 76
Orientate mount so shims
on mount are down and back on
center section. Not doing so will cause interference with the
cylinders.
Figure 76
Opener Mounts to Wing
31162
1
1
1
