Bin Lids and Silicone Sealant
(see Parts Manual section: Bin Assembly)
(see Operator Manual section: Operating Instructions)
Refer to Figure 58
Seal lid with silicone sealant provided.
Use adequate amount of silicone sealant to prevent
water leakage.
Bin Lids
Refer to Figure 59 and Figure 60
Keep lids closed. Keep tightly closed for operations.
1. Lift handle .
2. Swing handle out until hook releases from
U-bolt.
3. Move hook clear of U-bolt and re-close handle.
Figure 58
Bin Lids and Silicone Sealant
31106
Figure 59
Hopper Lid Latched
26344
1
1
1 2
2
Figure 60
Hopper Lid Unlatched
26345
2
1
