Great Plains Mfg., Inc.
18
Smartbox® Mount Kit
403-206M
12/12/2006
Great Plains Manufacturing, Inc.
Corporate Office P.O. Box 5060
Salina, Kansas 67402-5060 USA
Kit Parts List
Smartbox® Mount Kits
The part call-out numbers in this list match all Figures in the installation instructions. Your kit includes:
(Callout)
Part No.
Quantity per 403-
(Callout) Part Description
-196A -197A -198A -199A -200A -201A -218A -219A -220A
(11) 403-206M
1
1
1
1
1
1
1
1
1
(11)
This manual
(12) 116-001D
12
18
24
16
24
32
24
36
48
(12)
T-BANDER TUBE
(13) 403-190H
0
0
0
2
2
2
0
0
0
(13)
SUPPORT TUBE WLDMNT
(14) 403-191H
6
6
6
6
6
6
8
8
8
(14)
SMARTBOX STANDOFF SUPPORT BKT
(15) 403-192H
2
2
2
0
0
0
0
0
0
(15)
SUPPORT TUBE WLDMNT - 12 ROW
(16) 403-202H
0
8
12
0
12
16
0
18
24
(16)
SMARTBOX METER SPLITTER WLDMNT
(17) 403-225H
0
0
0
0
0
0
3
3
3
(17)
SMARTBOX SUPPORT ARM SHORT
(18) 403-319D
24
20
24
32
24
32
48
36
48
(18)
SMART BOX HOLD DOWN CLAMP
(19) 403-363D
0
0
0
0
0
0
2
2
2
(19)
TUBE SQ. 3.0X.25X260
(20) 403-364D
0
0
0
0
0
0
3
3
3
(20)
TUBE SQ. 3.0X.25X48.00
(21) 403-365D
0
0
0
0
0
0
2
2
2
(21)
STIFFENER BAR
(22) 800-126C
24
18
24
32
48
64
48
72
96
(22)
CLAMP WRM DRV #5 SS (.44-.70)
(23) 800-163C
0
96
144
0
144
192
0
72
96
(23)
CLIP U-TYPE NUT 1/4-20 SLF-RET
(24) 800-321C
12
18
24
16
24
32
24
36
48
(24)
HOSE CLAMP NO.12 3/4 ID
(25) 802-004C
48
104
144
64
144
192
0
72
96
(25)
HHCS 1/4-20X3/4 GR5
(26) 802-079C
24
20
24
32
24
32
48
36
48
(26)
HHCS 3/8-16X1 1/4 GR5
(27) 802-223C
24
20
24
32
24
32
48
36
48
(27)
HHCS 3/8-16X4 GR5
(28) 803-021C
24
24
24
24
24
24
44
44
44
(28)
NUT HEX 5/8-11 PLT
(29) 803-088C
48
0
0
64
0
0
0
0
0
(29)
NUT HEX LOCK 1/4-20 FLG
(30) 803-169C
12
12
12
12
12
12
30
30
30
(30)
NUT HEX FLG. LOCK 1/2-13 PLT.
(31) 803-209C
48
40
48
64
48
64
96
72
96
(31)
NUT FLANGE LOCK 3/8-16 PLT
(32) 804-007C
48
104
144
64
144
192
0
72
96
(32)
WASHER FLAT 1/4 SAE PLT
(33) 804-022C
24
24
24
24
24
24
44
44
44
(33)
WASHER LOCK SPRING 5/8 PLT
(34) 805-185C
12
18
24
16
24
32
24
36
48
(34)
PIN COTTER .186 WIRE DIA
(35) 806-052C
12
12
12
12
12
12
16
16
16
(35)
U-BOLT 5/8-11 X 7 1/32 X 8 1/2
(36) 806-053C
0
0
0
0
0
0
6
6
6
(36)
U-BOLT 5/8-11 X 7 1/32 X 6 1/2
(37) 806-066C
6
6
6
6
6
6
15
15
15
(37)
U-BOLT 1/2-13 X 3 1/32 X 4
(38) 816-358C
12
18
24
16
24
32
24
36
48
(38)
SGS HOSE 122 RIBS
(39) 817-655C
12
18
24
16
24
32
24
36
48
(39)
T-BANDER
