SARGENT 351 Series Aluminum Closer - Manual (Page 4)

ATTACH FOOT BRACKET TO FRAME STOP.
7"
9 7/8" 10 1/4"
7 3/8"
120º
DIM.
B
DIM.
A
MAX. DOOR
OPENING
180º
TOP OF
DOOR
STOP
C OF HINGE PIVOT
DIM. A
L
TOP VIEW
1 1/4"
2 1/2"
5/16"
7/8"
1/2"
DOOR
C OF HINGE PIVOT
(BUTT HINGE SHOWN)
DIM. B
2 3/8"
2 1/2"
#12 x 3" WOOD SCREWS
OR #12-24 x 5/8 FLAT HEAD
MACHINE SCREWS
USING WRENCH ON BOTTOM END OF SPINDLE, ROTATE 45º AND ASSEMBLE MAIN ARM TO CLOSER AS SHOWN, AND THEN INSERT ROD END INTO
SWIVEL ARM AND TIGHTEN ARM SCREW POSITIONING ARM 1 1/2" AWAY FROM DOOR.
#12 X 3" WOOD SCREWS OR
#12-24 X 2 1/4" MACHINE
SCREW.
SEE PAGE 6 FOR
MORTISE NUTS
9"
CAUTION: DOOR CLOSER WILL NOT
OPERATE PROPERLY IF ARM IS NOT
INDEXED CORRECTLY.
PRELOAD
APPROX. 45
º
POSITION OF MAIN ARM
WHEN ASSEMBLING
TO SPINDLE
RIGHT HAND DOOR
FOOT BRACKET
ARM SCREW
SWIVEL ARM
1 1/2"
MAIN ARM
L
LEFT HAND VIEW OF INDEX
45 º
INDEX MARK
ON SPINDLE
MAIN ARM
INDEX MARK
ON SPINDLE
RIGHT HAND VIEW OF INDEX
45 º
MAIN
ARM
1
2
3
4
5
1
2
3
4
5
INSTALL DOOR CLOSER TO FRAME WITH SPRING
ADJUSTMENT NUT AWAY FROM HINGE.
RIGHT HAND
DOOR SHOWN
NOTE: 351 CLOSER BODIES ARE
NON HANDED. IT IS IMPORTANT
THAT THE CLOSER BODY BE MARKED
WITH “RH” SYMBOL AT TOP, FOR LEFT
HAND DOORS. “LH” SYMBOL AT TOP
FOR RIGHT HAND DOORS.
LH
LEFT HAND DOOR SHOWN. RIGHT HAND
DOOR DIMENSION OPPOSITE.
1
2
DO NOT USE THIS MOUNTING FOR
“SWING CLEAR” HINGES.
3
THIS DIMENSION IS TAKEN FROM HINGE
EDGE OF DOOR FOR INVISIBLE HINGES.
DRILL & TAP AND USE SCREWS PROVIDED OR USE MORTISE
NUTS WHEN REQUIRED.
Copyright © 2009, Sargent Manufacturing Company,
an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
A7342A
351 FUSIBLE LINK PARALLEL ARM APPLICATION INSTRUCTION
4
