SARGENT 351 Series Aluminum Closer - Manual (Page 2)

INSTALL DOOR CLOSER TO DOOR WITH
SPRING ADJUSTMENT NUT AWAY FROM HINGE.
NOTE: 351 CLOSER BODIES ARE NON HANDED.
IT IS IMPORTANT THAT THE CLOSER BODY BE
MARKED WITH “RH” SYMBOL AT TOP, FOR RIGHT
HAND DOORS. “LH” SYMBOL AT TOP FOR LEFT
HAND DOORS.
ATTACH ARM WITH INDEX MARK ON SPINDLE ALIGNED AS SHOWN. SECURE WITH SCREW AND
WASHER. INSERT ROD END INTO SWIVEL ARM AND TIGHTEN ARM SCREW AS SHOWN BELOW. ATTACH FOOT TO FRAME WITH PIVOT
AWAY FROM HINGE.
RIGHT HAND
DOOR SHOWN
DIM. "B"
DIM. "A"
RH
ALTERNATE
STANDARD 8 3/16"
6 13/16"
11 7/16"
10 1/6"
MOUNTING
110º
DIM.
B
DIM.
A
MAX. DOOR
OPENING
IMPORTANT: USE ALTERNATE MOUNTING IF DOOR CAN
OPEN BEYOND LIMITS SHOWN FOR STANDARD MOUNTING
IF BUTT, FRAME AND WALL CONDITIONS PERMIT
DOOR WILL OPEN 180º
135º
ARM
TYPE
HOLD OPEN
ARM WITH
FUSIBLE
LINK
RIGHT HAND DOOR SHOWN. LEFT HAND
DOOR OPPOSITE.
1
2
THIS DIMENSION IS TAKEN FROM HINGE
EDGE OF DOOR FOR INVISIBLE HINGES.
C OF HINGE PIVOT:
BUTTS, OFFSET PIVOTS, SWING CLEAR,
CENTER HUNG OR INVISIBLE HINGES
#12 x 3 WOOD
SCREWS OR
#12-24 X 2 1/4
FLAT HEAD
MACHINE SCREWS
SEE PAGE 6 FOR
MORTISE NUTS
L
90 º
RIGHT HAND DOOR SHOWN (LEFT HAND DOOR OPPOSITE)
ROD
ARM
SCREW
SWIVEL ARM
POSITION OF
MAIN ARM WHEN
ASSEMBLING
TO SPINDLE
DRILL & TAP AND USE SCREWS PROVIDED OR USE MORTISE
NUTS WHEN REQUIRED. SEE PAGE 6 FOR MORTISE NUTS.
USE TEMPLATE A6753 FOR 25-OLC ARM
(LOW PROFILE)
PIVOT
9"
2 1/2"
9/16"
1 1/8"
TOP OF DOOR
2"
FUSIBLE LINK ARM ASSEMBLY SHOWN IS
HANDED. HAND OF ARM MUST BE THE
SAME AS HAND OF DOOR.
1
2
3
4 5
INDEX MARK
ON SPINDLE
MAIN ARM
2
Copyright © 2009, Sargent Manufacturing Company,
an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
A7342A
A
B C
351 STANDARD APPLICATION INSTRUCTIONS WITH FUSIBLE LINK
