Installing and Upgrading Internal Components in Cisco 3800 Series Routers
OL-5975-04
AIM Installation and Removal
Figure 57
Metal Standoffs
Step 3
Install the two machine-thread metal standoffs in place of the two screws labeled A in
1/4-inch nut driver to tighten the standoffs. See
Caution
Make sure that the standoffs are straight when installed. Tighten them gently but firmly. The shoulder
must be seated tight against the motherboard.
121202
