TRANSMIG 200i
Manual 0-5209 2-5 INTRODUCTION
2.10 Specifications
Description Transmig 200i
(South Pacific Version)
Transmig 200i
(Asia Version)
Plant Part No
Power Source (Packed) Part No W1005200
W1005201 W1005200M
-
Power Source Dimensions H435mm x W266mm x D617mm H435mm x W266mm x D617mm
Power Source Mass 26kg 26kg
Cooling Fan Cooled Fan Cooled
Welder Type
Multi Process Inverter Power
Source
Multi Process Inverter Power
Source
Australian Standard AS 60974.1 / IEC 60974-1 AS 60974.1 / IEC 60974-1
Number of Phases Single Phase Single Phase
Nominal Supply Voltage 240V ± 15% 240V ± 15%
Nominal Supply Frequency 50/60Hz 50/60Hz
Welding Current Range (MIG Mode) 10 – 210A 10 – 210A
Wirefeed Speed Range 2.5 – 18MPM 2.5 – 18MPM
Factory Fitted Supply Plug Rating 15 Amps Asian Style Input Plug
Effective Input Current (I
1eff
) 15 Amps 15 Amps
Maximum Input Current (I
1max
) 29 Amps 29 Amps
Single Phase
Generator Requirement
7 kVA 7 kVA
MIG (GMAW)
Welding Output, 40 o C, 10 min.
210A @ 20%, 24.5V
130A @ 60%, 20.5V
101A @ 100%, 19.0V
210A @ 20%, 24.5V
130A @ 60%, 20.5V
101A @ 100%, 19.0V
STICK (MMAW)
Welding Output, 40 o C, 10 min.
200A @ 25%, 28V
130A @ 60%, 25.2V
101A @ 100%, 24.0V
200A @ 25%, 28V
130A @ 60%, 25.2V
101A @ 100%, 24.0V
TIG (GTAW)
Welding Output, 40 o C, 10 min.
200A @ 25%, 18V
130A @ 60%, 15.2V
101A @ 100%, 14.0V
200A @ 25%, 18V
130A @ 60%, 15.2V
101A @ 100%, 14.0V
Open circuit voltage (VRD inactive) 79V 79V
Protection Class IP23S IP23S
Table 2-1: Transmig 200i Specification
Note 1: The Effective Input Current should be used for the determination of cable size & supply requirements.
Note 2: Motor start fuses or thermal circuit breakers are recommended for this application. Check local re-
quirements for your situation in this regard.
Note 3: Generator Requirements at the Maximum Output Duty Cycle.
NOTE
Transmig 200i Plant Part No. W1005200M (Asia Version) is not fitted with VRD. Additional safety
precautions may be required when using unit in an environment with increased hazard of electric
shock . Please refer to relevant local standards for further information prior to using in such areas.
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings,
all capacities, measurements, dimensions and weights quoted are approximate only. Achievable
capacities and ratings in use and operation will depend upon correct installation, use, applications,
maintenance and service.
