TRANSMIG 200i
Manual 0-5209 2-3 INTRODUCTION
2.05 Description
The Cigweld Transmig 200i is a self contained single
phase multi process welding inverter that is capable
of performing GMAW/FCAW (MIG), MMAW (Stick)
and GTAW (Lift TIG) welding processes. The unit is
equipped with an integrated wire feed unit, voltage
reduction device (VRD applicable in stick mode only.
Note VRD is not fitted to the Asia Version Plant Part
No: W1005200M), digital voltage and amperage
meters, and a host of other features in order to fully
satisfy the broad operating needs of the modern
welding professional. The unit is also fully compliant
to Australian Standard AS 60974.1 and IEC 60974.1.
The Transmig 200i provides excellent welding per-
formance across a broad range of applications when
used with the correct welding consumables and
procedures. The following instructions detail how
to correctly and safely set up the machine and give
guidelines on gaining the best efficiency and quality
from the Power Source. Please read these instructions
thoroughly before using the unit.
2.06 User Responsibility
This equipment will perform as per the information
contained herein when installed, operated, maintained
and repaired in accordance with the instructions pro-
vided. This equipment must be checked periodically.
Defective equipment (including welding leads) should
not be used. Parts that are broken, missing, plainly
worn, distorted or contaminated, should be replaced
immediately. Should such repairs or replacements
become necessary, it is recommended that such re-
pairs be carried out by appropriately qualified persons
approved by CIGWELD. Advice in this regard can
be obtained by contacting an Accredited CIGWELD
Distributor.
This equipment or any of its parts should not be al-
tered from standard specification without prior written
approval of CIGWELD. The user of this equipment
shall have the sole responsibility for any malfunction
which results from improper use or unauthorized
modification from standard specification, faulty
maintenance, damage or improper repair by anyone
other than appropriately qualified persons approved
by CIGWELD.
2.07 Transporting Methods
This unit is equipped with a handle for carrying
purposes.
WARNING
ELECTRIC SHOCK can kill. DO NOT TOUCH
live electrical parts. Disconnect input
power conductors from de-energized
supply line before moving the welding
power source.
!
WARNING
FALLING EQUIPMENT can cause serious
personal injury and equipment damage.
Lift unit with handles built into the top of the front and
rear moulded panels.
Use handcart or similar device of adequate capacity.
If using a fork lift vehicle, place and secure unit on a
proper skid before transporting.
2.08 Packaged Items
Transmig 200i Plant (Part No. W1005200)
• Transmig 200i Inverter Power Source
• Tweco Fusion 250 Mig Torch 3m
• Comet Professional Argon regulator / Flowmeter
(Not included in Asia Version Plant Part No.
W1005200M)
• Feedrolls 0.6/0.8mm "V" groove (fitted),
0.9/1.2mm "V" groove, 1.0/1.2mm "U" groove,
0.8/0.9mm "V" knurled, 1.2/1.6mm "V" knurled
• Contact Tips 0.6mm, 0.8mm (fitted), 0.9mm,
1.0mm
• Electrode Holder with 4m lead
• Work Clamp with 4m lead
• Shielding Gas hose assembly
• Shielding Gas adaptor (supplied in Asia Version
Plant Part No. W1005200M only)
• Operating Manual
Transmig 200i Power Source (Part No. W1005201)
(South Pacific only)
• Transmig 200i Inverter Power Source
• Shielding Gas hose assembly
• Operating Manual
