ULTRAFEED VA 4000
6-6 September 18, 2012
6.06 Replacement Parts
Item # Item # Item # Item # Item # Qty Qty Qty Qty Qty Description Description Description Description Description Catalog # Catalog # Catalog # Catalog # Catalog #
1 1 Gear, Idler Assy,WF 871001PKD
2 1 Center Guide 375838-004
3 2 Cover Mount Bolt, Packaged Thumb Screw 26372003
4 3 Insulator, Screw, mtg, 4R Plate 870431
5 1 Buss Bar 872030
6 1 Fitting, Swivel Hose, WF 870428
7 1 Gas Nipple, #10-32 UN, 2R Plate 375298
8 1 Barb Extended, #10-32, VA4000 870724
9 1 Pressure Arm, Cast Assy, WF 870510
10 1 Feedplate Assy, Left, WF 870502
11 1 Base Assy, VA4000 871358WBLK
1
2
3
4
5
6
7
8
9
10
11
