ULTRAFEED VA 4000
September 18, 2012 4-5
4.04 Power Source Compatibility
The Ultrafeed VA 4000 wire feeder will work with any Thermal Arc CV or CC/CV power source. If the Thermal Arc
power source only offers a 5 pin amphenol connector and AC voltage outlets, a 870000-001 adapter cable will
be required to connect between the 19 pin control cable of the wire feeder and the 5 pin amphenol connector
and AC voltage outlets of the power source.
If the Thermal Arc power source only offers a 14 pin amphenol connector, a 870093B-001 adapter cable will be
required to connect between the 19 pin control cable of the wire feeder and the 14 pin amphenol connector of the
power source.
The Ultrafeed VA 4000 will also work with most competitive power sources that provide 115 VAC and require a relay
closure to become energized.
4.05 Power Source Compatibility Details
Machine Details
PowerMaster 500 Fully Compatible
PowerMaster 500P For GMAW - Set Motor Control S1 Switches for:
Runin Speed 25%, Motor Ramp Rate 0.3 S, Arc Established ON.
For Pulse GMAW - Set Motor Control S1 Switches for:
Runin Speed - 75%, Motor Ramp Rate - 0.2 S, Arc Established - ON
ExcelArc 6045 Fully Compatible
ExcelArc 8065 For GMAW - Set Motor Control S1 Switches for:
Runin Speed 50%, Motor Ramp Rate 0.2 S, Arc Established ON.
Fabstar 4030 Fully Compatible except: Actual arc amps on the wire feeder will not be show
and preset volts on the power source will not be displayed.
ArcMaster 300 MST Fully Compatible
ArcMaster 400 MST Fully Compatible
ArcMaster 400 MSTP Fully Compatible
