ARCMASTER 200 AC/DC
April 13, 2006
3-5
3.09 Specifications
Table 3-3: Parameter Specifications
130A / 16V @ 60%
Single phase
160A
27V
40%
8.7
5.2
0.5
0.13
Amperage Draw @ Rated Load
No Load Amps
38
1.6
Parameter
200 AC/DC
Rated Output
Amperes
Volts
Duty Cycle
200
18
20%
Duty Cycle
TIG
200A / 18V @ 20%
160A / 17V @ 40%
100A / 14V @ 100%
STICK
160A / 27V @ 40%
130A / 26V @ 60%
100A / 24V @ 100%
Output Current
TIG
5 – 200 (DC)
5 – 200 (AC) @ 60Hz, 50% Cleaning
Range
STICK
5 – 160 (DC)
5 – 160 (AC) @ 60Hz, 50% Cleaning
Open Circuit Voltage
65V
Dimensions
Width
7.08” (180mm)
14.7” (360mm)
16.54” (420mm)
Output Amperes
Output Volts
Height
Length
Weight
41.8 lb. 19 kg
Output @ Rated Load
Rated Input Voltage
Duty Cycle
KVA
KW
230V
Output @ No Load
KVA
KW
Input Volts Single Phase
