Ultra-cut 200 xt – Tweco 200 XT Ultra-Cut Plasma Cutting System With Automated Gas Control User Manual
Page 49
ULTRA-CUT 200 XT
Manual 0-5304
INSTALLATION
3-25
Preparation
1. Remove the screws securing the Cover Panel to the Module.
Loosen or remove 2 screws
Remove 2 Screws
Art # A-09144_AB
2. Carefully remove the cover from the module noting the attached wire harness that connects to J4. Remove
the wire harness and then set the cover to the side.
Art # A-09145
