Tweco 300 XT Auto-Cut 380V - Manual (Page 59)

AUTO-CUT 300 XT
Manual 0-5261 OPERATION 4-11
CCM Status Code
Group 4 -- Torch Coolant System
Code Message Remedy / Comments
401 Coolant Level low Check coolant level, add as needed.
402
Low coolant fl ow
Coolant fl ow as measured by fl ow switch FS1 is less than 0.7 gpm; Clogged fi lter; Restriction
in torch lead or head; Wrong style consumables; broken or defective torch coolant tube/check
valve; Defective pump or bypass valve.
403
Coolant overheated Coolant supply temperature exceeded 75 degrees Celcius (167F). Operating with either lower
side panel loose or removed; Coolant fan failed; radiator fi ns clogged with dirt.
404
Coolant System not
ready.
Proper coolant fl ow of 0.7 gpm as measured by fl ow switch FS1 was not obtained during up
to 4 minutes of Priming. New installation can require additional Priming cycle(s) to fi ll hoses
with coolant; cylce power to restart Priming; Coolant hoses or torch hoses reversed; Clogged
coolant fi lter; Restriction in torch lead or head; Wrong style consumables; broken or defective
torch coolant tube/check valve; Defective pump or bypass valve.
405
Low Coolant Level
Warning Low coolant level during cut, does not stop cut.
Add coolant as required.
406 Not used Reserved for other models.
407
Coolant overheated,
high ambient. Ambient greater than 40 deg C results in coolant overheating. Reduce cutting duty cycle; Re-
duce ambient; Add separate cooler.
NOTE
There are no 500 codes
