Manual No. 0-4748 4-11 OPERATION
ULTRA-CUT 100
4.07 Power Supply Status Codes
On start-up and during operation, the power supply control circuitry performs various tests. If the circuitry
detects a condition requiring operator attention, the status indicator on the control panel flashes a 2-part code
to indicate a code group and then a particular condition within the group. After 4 seconds, the sequence
repeats.
Example: Indicator flashes 4 times; the condition is in group 4. After a 1.2 second delay, the indicator blinks
3 times; the condition code is 4-3, indicating that the coolant is overheating. After a 4-second delay, the
indicator repeats the sequence until the condition is corrected.
Some conditions can be active indefinitely, while others are momentary. The power supply latches momentary
conditions; some momentary conditions can shut down the system. The indicator may show multiple condi-
tions in sequence; it is important to recognize all possible conditions that may be displayed.
Note
These codes are for systems with Firmware versions 2.4 or later. If your system’s Firmware is a prior version,
contact your distributor for updates.
Error
Code Error Remedy / Comments
1-1
System not Enabled or
Missing AC Input Phase
Plasma Enable Off ; External E-Stop Activated or
CCM TB1-1&2 jumper missing; Missing AC Phase;
No power to GCM 2000 or 2010 Gas Control, check
GCM control cable connected, reset CP4 or CP5
circuit breaker in power supply, blown fuse F19 in
GCM.
1-2 Pilot Ignition Failure
Pilot did not start within 15 seconds.
Preflow pressure too high; Defective Arc Starter
1-3 Lost Pilot
Pilot went out without shutoff signal; Preflow pressure
too high; cut current set too low for consumables.
1-4 Loss of Transfer
Arc transfer (>50 ms.) then arc lost with START still
on. Standoff too high; Current set too low.
1-5 Off the Plate Function not currently enabled
1-6 Pilot Timed out w/o Transfer
Must transfer from Pilot to Cutting Arc in 85 ms.
(SW8-1 OFF) or 3 sec. (SW8-1 ON). Standoff too
high or void in work under torch; cut current too low
for consumables; Preflow pressure too low.
1-7 Tip Saver Function not currently enabled.
1-8 Possible Shorted Torch
Detected tip voltage too close to electrode voltage.
Plasma flow/pressure too low; Plasma leak; cut
current too high; shorted torch body; consumable
parts worn out.
Fault Code Key
