ULTRA-CUT 100
Manual 0-4748 2-5 SPECIFICATIONS
2.10 Gas Requirements
The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators
shall be double stage. The chart includes gases which may not be used in all applications.
Ultra-Cut 100 Power Supply: Gas Pressures, Flows, and Quality Requirements
Gas Quality Minimum Pressure Flow
O2 (Oxygen) 99.5% Purity
(Liquid recommended)
120 psi
8.3 bar / 827 kPa
70 scfh (2000 l/h)
N2 (Nitrogen) 99.5% Purity
(Liquid recommended)
<1000 ppm O2, <32 ppm
H2O)
120 psi
8.3 bar / 827 kPa
200 scfh (5700 l/h)
Compressed
or Bottled Air
Clean, Dry,
Free of Oil (see Note 1)
120 psi
8.3 bar / 827 kPa
250 scfh (7000 l/h)
H35 (Argon-Hydrogen)
H35 = 35% Hydrogen,
65% Argon
99.995% Purity
(gas recommended)
120 psi
8.3 bar / 827 kPa
90 scfh (2550 l/h)
H2O (Water) See Note 2 50 psi (3.5 bar) 10 gph (38 lph)
Note 1: The air source must be adequately fi ltered to remove all oil or grease. Oil or grease
contamination from compressed or bottled air can cause fi res in conjunction with oxygen.
For fi ltering, a coalescing fi lter able to fi lter to 0.01 microns should be placed as close as
possible to the gas inlets on the Gas Control Module.
Note 2: The tap water source does not need to be deionized, but in water systems with extremely high mineral content a water softener
is recommended. Tap water with high levels of particulate matter must be fi ltered.
2.11 Gas Applications
Ultra-Cut-100 Gas Applications
MATERIAL MILD STEEL STAINLESS STEEL ALUMINUM
OPERATION GAS TYPE GAS TYPE GAS TYPE
PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD
30A CUT Air O2 O2
Air Air Air Air Air Air
N2 N2 H20 N2 N2 H20
50 A CUT Air O2 Air
Air Air Air Air Air Air
N2 N2 H20 N2 N2 H20
70 A CUT Air O2 Air
Air Air Air Air Air Air
N2 N2 H20 N2 N2 H20
85A CUT Air Air Air
100 A CUT Air O2 Air
N2 H35 N2 N2 H35 N2
N2 N2 H20 N2 N2 H20
