ual 0-2690
A-7
APPENDIX
NOTE
Piercing materials 3/4 inch (19.1 mm) and over may shorten torch consumable parts life.
Metric Measurements
Nitrogen Plasma Cutting Data Chart
Maximizer 300 Torch
Aluminum
Nitrogen Plasma / Water Secondary
Electrode
Gas
Distributor
Tip End Cap Amperage
Output
Volts
Speed Standoff
Plasma
Pressure
Plasma
Flowball
Secondary
Flow
Pierce
Delay
Pierce
Height
Cat. No. Cat. No. Cat. No. Cat. No. amps vdc m / min mm bar gal/hr seconds mm
20-1023 20-0008 20-1031 20-1004 100 160 5.72 4.78 5.52 90 8.00 0.00 9.53
20-1023 20-0008 20-1031 20-1004 100 160 3.81 4.78 5.52 90 8.00 0.25 9.53
20-1023 20-0008 20-1031 20-1004 100 160 2.03 4.78 5.52 90 8.00 0.25 9.53
20-1023 20-0008 20-1031 20-1004 100 160 1.27 4.78 5.52 90 8.00 0.25 9.53
20-1023 20-0008 20-1031 20-1004 100 165 0.64 4.78 5.52 90 8.00 0.37 9.53
20-1023 20-0008 20-1031 20-1004 100 175 0.51 4.78 5.52 90 8.00 0.50 9.53
20-1023 20-0008 20-1032 20-1004 150 145 4.45 4.78 5.52 90 9.00 0.25 9.53
20-1023 20-0008 20-1032 20-1004 150 150 3.30 4.78 5.52 90 9.00 0.25 9.53
20-1023 20-0008 20-1032 20-1004 150 150 2.41 4.78 5.52 90 9.00 0.25 9.53
20-1023 20-0008 20-1032 20-1004 150 150 1.65 4.78 5.52 90 9.00 0.35 9.53
20-1023 20-0008 20-1032 20-1004 150 155 1.02 4.78 5.52 90 9.00 0.35 9.53
20-1023 20-0008 20-1032 20-1004 150 162 0.51 4.78 5.52 90 9.00 0.50 12.70
20-1023 20-0008 20-1033 20-1004 225 150 3.81 4.78 5.52 90 8.00 0.00 9.53
20-1023 20-0008 20-1033 20-1004 225 150 3.18 4.78 5.52 90 8.00 0.00 9.53
20-1023 20-0008 20-1033 20-1004 225 155 2.41 4.78 5.52 90 8.00 0.25 9.53
20-1023 20-0008 20-1033 20-1004 225 160 1.78 4.78 5.52 90 8.00 0.25 9.53
20-1023 20-0008 20-1033 20-1004 225 160 1.52 4.78 5.52 90 8.00 0.50 9.53
20-1023 20-0008 20-1033 20-1004 225 165 1.02 4.78 5.52 90 8.00 1.00 9.53
20-1023 20-1009 20-1034 20-1005 300 150 1.78 6.35 5.52 120 8.00 0.25 12.70
20-1023 20-1009 20-1034 20-1005 300 155 1.27 6.35 5.52 120 8.00 0.25 12.70
20-1023 20-1009 20-1034 20-1005 300 160 0.76 6.35 5.52 120 8.00 NR NR
20-1023 20-1009 20-1034 20-1005 300 165 0.38 6.35 5.52 120 8.00 NR NR
31.8
38.1
15.9
19.1
25.4
19.1
25.4
15.9
19.1
12.7
6.4
9.5
4.8
6.4
9.5
12.7
6.4
9.5
15.9
12.7
Material
Thickness
mm
3.2
4.8
