tekmarNet ® Thermostat 557
Installation & Operation Manual
557_D
09/14
Zoning Replaces: 09/13
© 2014 557_D - 09/14
1 of 52 A Watts Water Technologies Company
The tekmarNet ® Thermostat 557 is a
communicating touchscreen thermostat
designed to operate either: a hydronic
radiant floor with a two stage heat pump
(water-to-air or air-to-air) for heating
& cooling and an emergency backup
heating system; or two stages of heating
and two stages of cooling. There are
three auxiliary sensor inputs that can
be used to measure room, floor, outdoor
or duct temperature. The optional floor
sensor allows precise heating of radiant
floors. Relative humidity level can be
measured and controlled using either
the built-in or external humidity sensor.
The large touchscreen display allows
you to easily adjust 7-day programmable
schedules and room temperatures to
optimize comfort and energy savings.
The 557 can connect to tekmarNet
®
controls using two or four wires or it can
operate as a stand-alone device.
Introduction
Energy Saving Features
Programmable Schedule
Zone Synchronization
Zone Post Purge
Warm Weather Shut Down
Cooling Interlock
Auto Heating Cycle
Temporary Hold
Away Scene Key •
•
•
•
•
•
•
•
Additional Features
3 Auxiliary Sensor Inputs
Air Group Master
Backlight
Daylight Savings Time
Exercising
Freeze Protection
Heat / Cool Priority
Network Schedule Master or
Member
Optimum Start
Outdoor & Floor Temperature
Display
Radiant Floor Heating & Cooling
Relative Humidity Control
Room Temperature Limiting
Scenes
Touchscreen Technology
tekmarNet
® Communication
Compatible
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
