tekmarNet ® Address Section J
When connected to a tekmarNet ® system, each thermostat will be automatically given an
address. The address is useful as a troubleshooting tool to locate thermostats with errors
and also allows room naming on a Gateway.
The address consists of the bus water temperature followed by the thermostat device
number. Available buses are b (boiler), 1, 2 and 3. Device numbers range from 01 to
24. If the thermostat is used without a tekmarNet
® system control, the bus number is not
shown.
When using the thermostat together with a Gateway, it is important that each address be
changed to be manually set. This allows each thermostat to be named on the Gateway.
If two thermostats are manually set to the same address, an error message will appear.
The error remains until one of the addresses is manually changed to a vacant address
or to Auto.
It is highly recommended to keep a documented list of thermostat addresses. This is
extremely helpful when troubleshooting errors. The tekmarNet
® system control will display
the addresses of thermostat’s that have errors. By referring to the address documentation,
it simplifies the process to locate and correct error messages.
Access Levels Section I
The thermostat Toolbox menu supports four access levels: Installer (INST), User
(USER), Limited (LTD), and Secure (SEC). The access level can be adjusted when
the thermostat is unlocked. There are two locations to lock the thermostat:
1) Locally on the back of the thermostat using the Lock switch
2) Globally on the tekmarNet ® system control using the Lock switch or Access level
(if installed)
Both the local and global lock settings must be set to unlock before the thermostat
access level is adjustable.
The selection of the access level is dependent on the use of the building and the
type of occupants.
Installer - Suitable for HVAC installers only. Times out to User access level after 24
hours.
User - Suitable for most residential homeowners.
Limited - Suitable for rental properties or commercial buildings where some level of
temperature adjustment is required.
Secure - Suitable for schools, churches, and other public buildings where temperature
adjustment is not desired.
Screen Clean Menu Section K
Entering the Screen Clean menu gives you 30 seconds to clean the thermostat and
display with a moist cloth. Do not use solvents to clean the thermostat.
