Troubleshooting
Should a problem arise and the Jockey 3‘s LEDs are not lit correctly, in most cases this is probably caused by installed MIDI software (e.g. MidiYoke,
Maple Virtual MIDI Cable, OSCulator, Bome Midi Translator etc.).
In order to solve the problem proceed as follows:
1. In Traktor open the adjustment dialogue by clicking the small cog wheel in the upper right corner.
2. Open the category “Controller Manager“.
3. For the following device entries the following port assignments have to be configured:
4. Operation
After connecting and configuring Reloop Jockey 3 Remix correctly for the DJ software, Traktor 2 can now be used. If Traktor Pro 2 is being used,
it is possible to fully utilize the Jockey 3 Remix user interface. There are some limitations for Traktor LE 2 regarding effect control, the number of
usable decks and the hot cue assignment.
4.1 Traktor Function Assignment
nOTe! In the following the whole Traktor function assignment will be described. Some features are only available in Traktor Pro 2.
NOTE! To warrant ideal sample deck control another assignment on Deck C/D is necessary. For better overview all functions regarding sample
decks on your Jockey 3 Remix dispose of a blue background colour.
4.1.1 Track deck Control
devICe In-PORT OUT-PORT
Jockey 3 V* (2 Sample Decks) Reloop Jockey 3 Remix Reloop Jockey 3 Remix
Jockey 3 V* (Effects Deck A) Reloop Jockey 3 Remix Reloop Jockey 3 Remix
Jockey 3 V* (Effects Deck B) Reloop Jockey 3 Remix Reloop Jockey 3 Remix
nO FUnCTIOn FUnCTIOn WITH ACTIvATed SHIFT -T23-
T1 Pitchfader
Herewith it is possible to adjust the current deck's (see -T30-) pitch.
T2 Dry/Wet Dial
With this encoder it is spossible to adjust the effect's intensity. Effekt Change
If the Advanced Effect section is selected, it is possible to change the effect by
turning the encoder.
T3 Effect Parameter
In Advanced Effect Mode the parameters can be adjusted herewith.
Dry/Wet Fine Adjustment
If Chained Effect Mode is used, the single effects can be operated.
nOTe! In Traktor Le only the 1st parameter in Chained effect Mode works.
Effect Change
In Chained Effect Mode it is herewith possible to change the respective effect.
nOTe! In Traktor Le only the 1st effect from the effect section works.
T4 FX On Button
Activates the Advanced FX Section corresponding to the deck Fx Preset 1 Button consists of:
Beat Masher 2
Digital LoFi
Reverse Gain
T5 Effect Reset Function
In Advanced Effect Mode it is possible to reset the effect herewith.
FX B1 On
Activates and deactivates the 1st effect in Chained Effect Mode respectively.
Fx Preset 2 Button consists of:
Beat Masher 2
Filter
Flanger Pulse
T6 Effect Button 1
Activates and deactivates the Effect Button 1 in Advanced Effect Mode.
FX B2 On
Activates and deactivates the 2nd effect in Chained Effect Mode respectively.
Fx Preset 3 Button consists of:
Beat Masher 2
Reverb
Reverse Gain
T7 Effect Button 2
Activates and deactivates the Effect Button 2 in Advanced Effect Mode.
FX B3 On
Activates and deactivates the 3rd effect in Chained Effect Mode.
Fx Preset 4 Button consists of:
Delay
Filter
Reverb
T8 Loop Length
Turning the encoder varies a set loop's length.
Pressing the encoder sets an automatic loop with the adjusted loop length. The
loop ending point does not have to be set manually.
T9 Loop Shift
Turning the encoder shifts a set loop's position.
Pressing the encoder (de-)activates the loop-active function.
T10 Filter
Adjusts the filter effect for the active deck. Key Controller
Herewith the selected deck's key can be adjusted.
T11 Sample deck volume dial
Adjusts the assigned sample deck's volume.
T12 Pitch Bend Button -
Slows down the deck's pitch for as long as the button is being held.
T13 Pitch Bend Button +
Increases the deck's pitch for as long as the button is being held.
T14 Beat Jump Back (-4 beats)
Carries out a beat jump opposed to playback direction. Beat Jump Back (-16 beats)
Carries out a beat jump opposed to playback direction.
T15 Beat Jump Back (-1 beat)
Carries out a beat jump opposed to playback direction. Loop-In/Set Cue Button
Manually sets loop beginning point. Simultaneously a cue point is defined.
