5

Camera Adapter ES−500

メインパネル

Main panel

(注意)ベースステーションDS-560の出力は、VUで0dB、PEAKで-20dBを指示する時、基準レベル-20dBとなります。

AUDIO INの信号レベルが瞬間でもオーバーした時に点灯します。

AUDIO INの信号レベルを確認します。METER SELECTメーター切替スイッチ(  )によりVU/PEAKの切替えができます。

PEAK indicator

VU/PEAK meter

ハイパーリミッター機能をON/OFFします。ONにすると最大30dBまでリミッターが働き、音が歪むのを防ぎます。

LIMIT switch

AUDIO IN 入力音声のレベルを調整します。

LEVEL volume

P-MIC switch

ファンタム 48V コンデンサマイク使用の場合、入力切替スイッチ( )を - 60dB の位置にして、このスイッチを 48V( ON ) にします。

Lights on when the AUDIO IN input signal is over level even momentarily.

Used to confirm the AUDIO IN input signal level. VU mode or PEAK mode is selectable by METER

SELECT switch.

VU(VU meter) : from - 20dB to +3dB (indicated in upper scale)

PK(PEAK program meter) : from - 60dB to 0dB (indicated in lower scale)

The standard output signal level of the Base Station ES−600 is - 20dBm when the VU meter

indicates 0dB or PEAK meter indicates - 20dB.

VU(VU メーター) : 上段目盛, - 20dB ∼ +3dB.

PK(ピーク プログラム メーター) : 下段目盛, - 60dB ∼ 0dB.

Turns on/off the Hyper Limiter. When set to the ON position, the limiter works up to +30dB to

prevent the distortion of the audio output to the Base Station ES−600.

Adjusts the audio input level from a camcorder.

When using a phantom 48V condenser microphone, set to the 48V position to supply +48V DC

power to the microphone and select the -60dB position of the INPUT LEVEL select switch.

VU/PEAKメータ(  )をVUまたはPEAKメータに切り替えます。

METER SELECT switch

Selects the Meter mode, VU mode or PEAK mode.
