The ORACLE™ controller can only control either the Revolution Head or an
elektraDRIVE motor at one time. To perform 3-axis movements with both
the Revolution Head and a elektraDRIVE motor for a slider at the same time,
you will need two controllers.
The ORACLE™ is Intervalometer capable. To use this function, you will
need the $99.95 Camera Control Module.
FEATURES, SPECS & ACCESSORIES
Included Items:
• ORACLE™ Controller
• 100v-240v input (50-60Hz, 1.4A) AC Power Supply w/ North
America Wall Plug.
• 25ft CAT5 Cable
Optional Accessories:
• elektraDRIVE 12v DC Power Adapter
• elektraDRIVE 12v Battery
• 12v Y Adapter
• Australia / New Zealand Region Wall Cord
• F.I.G.S. / Continental Europe Region Wall Cord
Supported Features & Specifications:
• Backlit LCD display with menu and setting values.
• Fully adjustable controls for Max Speed, Dampening, &
Dead Band.
• Movement Recording / Memory Function with three memory
banks.
• Time Lapse control
• Premium Multi-Function Joystick
• Joystick orientation can be easily set in the menu.
• Cabling is CAT5 / CAT6 cable with RJ45 connectors (standard
network cable).
• Powered by standard AC power supply with wall plug, or
optional 12v DC adapter and battery pack.
• SmartLapse™ advanced time lapse recording option
• Rear Mount - Rotatable (Clamp from 0.5”-1.25”)
Operation Power Range
• 11.9 VDC to 15 VDC
• 4.16 Amps (minimum)
3
