SLIDER/DOLLY

MOTION CONTROL -

ADVANCED

In Advanced mode, you can program complex motor movements

on a slider/dolly/shuttle pod. If you need to create a complex time

lapse move, we recommend using the optional SmartLapse™ mode

as it is easier to program.

1:

Once in

Slider/TT

mode press the MENU button until you

get to the main menu

2. Select

Motion Control

Press the MIDDLE JOYSTICK BUTTON or ENTER to confirm.

3. Select

Advanced

by moving the joystick down

Press the MIDDLE JOYSTICK BUTTON or ENTER to confirm.

4.

Move the joystick up or down to select one of the

following:

ShootMoveShoot

,

Continuous

,

Stop

Motion

, or

No Intervlmtr

(Intervalometer)

Press the MIDDLE JOYSTICK BUTTON or ENTER to confirm.

Advanced

<

^

ShootMoveShoot

Continuous

v

Stop Motion

^

No Intervlmtr

Advanced

<

^

Note:

See page 17 for details on different shooting modes

5.

Press the 1 button to select

1:SLIDER

or the 2 button to

select

2:AXIS2

Quick Tip:

Move the joystick LEFT/RIGHT (X-Axis) to scroll through the sub-menus

for 1:SLIDER & 2:AXIS2

6.

The 9 Sub-Menus are as follows:

This setting tells the motor how long to remain on. Stepper motors

have two states. On and off. This setting determines how long the

motor is on for each step. The default setting is a good starting point for

time lapse work.

Note:

For more information on how a stepper motor works and how these

values effect movement, see the Stepper Motors Demystified section of

this manual.

The default is 0.05 S (seconds). We recommend leaving this at the

default for starting out.

Press the MIDDLE JOYSTICK BUTTON or ENTER to accept the setting.

SLIDER Motor ON

0.05

S

SLIDER Motor OFF

0.05

S

1:SLIDER

2:AXIS2

ENTER:Run

20
