14
Ο 5. Install the ESC on the right-hand side of the battery compartment with
hook and loop tape. The battery leads, switch leads and throttle leads will be
towards the rear of the model. Connect the ESC to the motor.
Ο 4. Install the battery with two hook and loop straps. Slots are provided on
the floor of the battery compartment for the straps to pass through. The natural
curl of the straps will allow them to be fed down one slot, under the battery
compartment floor, then up through the opposite slot.
Should you find that the rotation direction of your E-flite Power
Brushless Outrunner is opposite to that needed, reversing it is just
a matter of switching any two of the motor wires.
E-flite’s Power series brushless motors and Pro series controllers
are outfitted with red, blue and black power wires. Matching the
color is not critical to their operation, it only affects the direction
of rotation.
