8 E-flite Fokker DVII 250 Slow Flyer Assembly Manual
It is best to support the fuselage with the palm of your
hand while installing the servo screws. The plywood
structure is strong enough for the model and flight
loads but could fail if extreme downward pressure is
placed on it during the servo mount screw installation.
 6. Repeat Steps 2 through 5 to install the elevator
servo. Note the direction of the output of the
elevator servo.
 7. Use a pin drill and 1/16-inch (1.5mm) drill bit
to enlarge the outermost hole in the servo arm.
 8. Insert the micro pushrod connector into the servo
arm from the bottom of the horn as shown.
 9. Use a micro pushrod connector backplate to
secure the pushrod connector to the servo arm.
Use pliers to fully push the backplate tight on the
connector.
 10. Repeat Steps 7 through 9 so two servo arms
have been prepared for your servos.
