2 E-flite Fokker DVII 250 Slow Flyer Assembly Manual
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track
of its completion. Steps with a single circle () are
performed once, while steps with two circles ( )
indicate that the step will require repeating, such as for
a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Contents of Kit/Parts Layout
Replacement Parts
EFL1976 Wing Set
EFL1977 Fuselage
EFL1978 Tail Set
EFL1979 Cowling
EFL1980 Wheel Set
EFL1981 Landing Gear
EFL1982 Lower Gear Spreader
EFL1983 Wing Struts
EFL1984 Machine Gun Set
EFL1985 Hardware pack
Introduction
Loved by the pilots who flew it and feared by those
who flew against it, the Fokker DVII is regarded by
many as the greatest fighter of WWI. E-flite brings this
Great War legend to life with this remarkable foamy
slow flyer that comes out of the box loaded with scale
details. Details like molded machine guns, accurately
modeled interplane struts, a dummy Mercedes engine
and an intricately detailed cooling grille, just to name
a few. Even the vibrant trim scheme that comes pre-
printed on the foam is an authentic reproduction of
the markings on the DVII flown by German ace, Ernst
Udet.
When matched with E-flite’s Park 250 brushless
outrunner motor, the Fokker DVII 250’s featherlight
wing loading and stunning scale appearance make for
a majestic slow flyer experience unlike any other.
Important Information
Regarding Warranty Information
Please read our Warranty and Liability Limitations
section on Page 24 before building this product. If you
as the Purchaser or user are not prepared to accept the
liability associated with the use of this Product, you are
advised to return this Product immediately in new and
unused condition to the place of purchase.
Table of Contents
Specifications ......................................................... 1
Introduction ........................................................... 2
Important Information Regarding
Warranty Information ........................................ 2
Using the Manual ................................................... 2
Contents of Kit/Parts Layout .................................... 2
Recommended Radio Equipment ............................. 3
Required Tools and Adhesives ................................. 3
Brushless Outrunner Setup ...................................... 3
Optional Accessories .............................................. 3
Note on Lithium Polymer Batteries ........................... 3
Warning ................................................................ 3
Motor Installation - Carbon Tube ............................. 4
Motor Installation - Firewall Mount .......................... 5
Speed Control Installation ....................................... 6
Servo Installation .................................................... 7
Stabilizer and Rudder Installation ............................ 9
Connecting the Linkages ....................................... 11
Cowling Installation .............................................. 13
Scale Accessory Installation .................................. 14
Bottom Wing ....................................................... 14
Cabane Strut Installation ....................................... 14
Top Wing and Outer Strut Installation .................... 15
Landing Gear Installation ...................................... 16
Rigging Installation ............................................... 18
Center of Gravity ................................................. 22
Control Throws..................................................... 22
Preflight ............................................................... 23
Flying Your Fokker DVII Slow Flyer ........................ 23
Range Test Your Radio .......................................... 23
Safety Do’s and Don’ts for Pilots ............................ 24
Daily Flight Checks ............................................... 24
Warranty Information ........................................... 24
Compliance Information for the European Union .... 26
2009 Official Academy of
Model Aeronautics Safety Code ....................... 26
