Table of Contents
Introduction ................................................................2
Specifications .............................................................2
Contents of Kit/Parts Layout .........................................3
Required Electronics & Accessories ...............................4
Recommended High Performance Motor Setup* .............4
Extreme High Performance Motor Setup* ......................5
Optional Accessories ..................................................5
Additional Tools and Adhesives ....................................5
Important Information About Motor Selection .................6
Using the Manual .......................................................6
Warning ....................................................................6
Before Starting Assembly .............................................6
Warranty Information ..................................................7
Landing Gear Installation .............................................8
Aileron Hinging ........................................................12
Aileron Servos and Linkages ......................................14
Wing Installation ......................................................18
Stabilizer and Elevator ..............................................19
Rudder and Fin ........................................................22
Motor Installation ......................................................25
Rudder and Elevator Servos .......................................28
Receiver, Battery and ESC Install ................................34
Canopy Install ..........................................................36
Cowling Install .........................................................38
Control Throws .........................................................40
Center of Gravity ......................................................41
Range Test Your Radio ...............................................41
2005 Official AMA
National Model Aircraft Safety Code ......42
Introduction
Thank you for purchasing the Mini Edge 540 3D ARF,
which is based on the popular 33% Hangar 9® Edge 540
and is capable of the same extreme 3D performance you
get with larger models. Backed by E-flite’s high quality
reputation, the Mini Edge 540 should provide you with the
superior performance and features you are looking for in an
aerobatic park flyer.
We provide a 6.6:1 gearbox and a 12 x 6 propeller so you
can easily add our E-flite™ Park 400 Brushless motor for
extreme performance. The Mini Edge features lightweight
balsa and light-ply construction, UltraCote® covering,
fiberglass cowl and wheel pants, and carbon fiber landing
gear. The mid-wing design makes it ideal for aerobatics such
as hovering and other precision 3D maneuvers.
Specifications
Wingspan: 37.25" (945 mm)
Length: 34" (860 mm)
Wing Area: 297 sq in (19 sq dm)
Weight w/o Battery: 20–21 oz (570–595 g)
Weight w/ Battery: 24–26 oz (680–740 g)
