E-flite Mini Edge 3D ARF - Manual (Page 14)

14
  5. Work the aileron up and down several times to
work in the hinges and check for proper movement.
 6. Repeat Steps 1 through 5 for the remaining aileron.
Aileron Servos and Linkages
Required Parts
Wing panel (right and left)
Micro control connector (2)
2mm x 4mm screw (2)
3
3
/
8
" (85 mm) pushrod (2)
Control horn and backplate (2)
Servos: JR 241 Sub-micro servo (JRPS241) (2)
Large Arm w/Screws (JRPA212) (2)
Required Tools and Adhesives
Hobby knife 6-minute epoxy
6" (150mm) servo extension (2) String
Phillips screwdriver (small)
